SKF

51148M - SKF Single Direction Thrust Bearing - 240x300x45mm

Name: 51148M - SKF Single Direction Thrust Bearing - 240x300x45mm
Brand: SKF
SKU: 51148m-skf
Availability: InStock

SKU: 51148m-skf

Availability: In Stock ✅

BULK PRICING: Click Here to Enquire

C$3,277.92

51148M - SKF Single Direction Thrust Bearing - 240x300x45mm

Description

This 51148M bearing is a Single direction thrust bearing with a flat housing locating washer and a machined brass cage, ball centred. The bearing's dimensions are 240x300x45.

511	48	M
Single Direction Thrust Bearing	Bore Size - 240mm	Machined Brass Cage, Ball Centred

Product Information

BRAND:

SKU:51148m-skf

AVAILABILITY:In Stock ✅

WEIGHT:7.55 kg

Technical Data

Inside Diameter (mm):

240mm

Outside Diameter (mm):

300mm

Width (mm):

45mm

Cage Type:

Brass

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

234

Static Load Rating (kN):

1040

Fatigue Load Rating (kN):

23.6

Reference Speed Rating (r/min):

1100

Limiting Speed Rating (r/min):

1600

Description

This 51148M bearing is a Single direction thrust bearing with a flat housing locating washer and a machined brass cage, ball centred. The bearing's dimensions are 240x300x45.

511	48	M
Single Direction Thrust Bearing	Bore Size - 240mm	Machined Brass Cage, Ball Centred

Product Information

BRAND:

SKU:51148m-skf

AVAILABILITY:In Stock ✅

WEIGHT:7.55 kg

Technical Data

Inside Diameter (mm):

240mm

Outside Diameter (mm):

300mm

Width (mm):

45mm

Cage Type:

Brass

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

234

Static Load Rating (kN):

1040

Fatigue Load Rating (kN):

23.6

Reference Speed Rating (r/min):

1100

Limiting Speed Rating (r/min):

1600
