SKF
BTW140CM/SP -SKF Double Direction Angular Contact Thrust - 140x210x84
SKU
: btw140cm/sp-skf
Availability
: In Stock ✅
Bulk Pricing :
Description
Enhance the performance of your machinery with the SKF BTW140CM/SP Super Precision Angular Contact Thrust Ball Bearing. Specifically engineered for high-speed applications, these bearings provide exceptional accuracy and stability and are designed to axially locate the shafts of spindles in both directions. BTW140 CM/SP bearings offer a high-speed design and are intended for mounting in combination with NN30 K or N10 K Cylindrical Roller Bearings. The dimensions of this BTW140CM/SP bearing are 140x210x84mm.
| BTW | 140 | C | M | /SP |
|---|---|---|---|---|
| Basic Design Double Direction Angular Contact Thrust Bearing | 140mm - Bore Size | 60° Contact Angle | Two Machined Brass Cages, Snap-Type, Ball Centred | ISO Tolerance Class 5 Dimensional Accuracy, Class 4 Running Accuracy |
Key Features
High Precision
Manufactured with tight tolerances, the Super Precision BTW140 CM/SP bearing is manufactured by SKF to ensure a consistently high rotational accuracy and optimal performance.
Double Directional Loads
Capable of handling axial loads in both directions, the BTW140CM/SP Super Precision Angular Contact Thrust Bearing has a double direction design which provides enhanced versatility and reliability in machinery.
Angular Contact Design
The BTW140 CM/SP bearing is made up of two separable Single Row Angular Contact Thrust Ball Bearings with a 60° contact angle in a back-to-back arrangement. Configured in this way, and with the large number of balls the bearings contain, means these bearings can accommodate heavy axial loads in both directions while providing a high degree of system rigidity.
Product Information
SKU: Availability:
In Stock ✅
Technical Data
Inside Diameter (mm)
140mm
Outside Diameter (mm)
210mm
Width (mm)
84mm
Cage Type
Brass
Seals Or Shields
Open Type
Clearance
Standard
Dynamic Load Rating (kN)
106
Static Load Rating (kN)
375
Fatigue Load Rating (kN)
13.2
Grease Limiting Speed (r/min)
3200
Oil Limiting Speed (r/min)
3800
Preload
No Preload
Contact Angle
60
DescriptionEnhance the performance of your machinery with the SKF BTW140CM/SP Super Precision Angular Contact Thrust Ball Bearing. Specifically engineered for high-speed applications, these bearings provide exceptional accuracy and stability and are designed to axially locate the shafts of spindles in both directions. BTW140 CM/SP bearings offer a high-speed design and are intended for mounting in combination with NN30 K or N10 K Cylindrical Roller Bearings. The dimensions of this BTW140CM/SP bearing are 140x210x84mm.
Key FeaturesHigh PrecisionManufactured with tight tolerances, the Super Precision BTW140 CM/SP bearing is manufactured by SKF to ensure a consistently high rotational accuracy and optimal performance. Double Directional LoadsCapable of handling axial loads in both directions, the BTW140CM/SP Super Precision Angular Contact Thrust Bearing has a double direction design which provides enhanced versatility and reliability in machinery. Angular Contact DesignThe BTW140 CM/SP bearing is made up of two separable Single Row Angular Contact Thrust Ball Bearings with a 60° contact angle in a back-to-back arrangement. Configured in this way, and with the large number of balls the bearings contain, means these bearings can accommodate heavy axial loads in both directions while providing a high degree of system rigidity. Product InformationBRANDS: SKU: btw140cm/sp-skf Availability:In Stock ✅ 8.6 kg Technical DataInside Diameter (mm)140mm Outside Diameter (mm)210mm Width (mm)84mm Cage TypeBrass Seals Or ShieldsOpen Type ClearanceStandard Dynamic Load Rating (kN)106 Static Load Rating (kN)375 Fatigue Load Rating (kN)13.2 Grease Limiting Speed (r/min)3200 Oil Limiting Speed (r/min)3800 PreloadNo Preload Contact Angle60 | ||||||||||
Product InformationBRANDS: SKU: btw140cm/sp-skf Availability:In Stock ✅ 8.6 kg Technical DataInside Diameter (mm)140mm Outside Diameter (mm)210mm Width (mm)84mm Cage TypeBrass Seals Or ShieldsOpen Type ClearanceStandard Dynamic Load Rating (kN)106 Static Load Rating (kN)375 Fatigue Load Rating (kN)13.2 Grease Limiting Speed (r/min)3200 Oil Limiting Speed (r/min)3800 PreloadNo Preload Contact Angle60 | ||||||||||
