SKF
N1014KTNHA/HC5SP -SKF Cylindrical Roller Bearing - 70x110x20mm
SKU
: n1014ktnha/hc5sp-skf
Availability
: In Stock ✅
Bulk Pricing :
Description
This N1014KTNHA/HC5SP bearing is a single row super precision cylindrical roller bearing with a double ribbed inner ring, a glass fibre reinforced PEEK cage, a 1:12 tapered bore and a P5 accuracy class.. The bearing's dimensions are 70x110x20.
| N | 10 | 14 | K | TNHA | HC5 | SP |
|---|---|---|---|---|---|---|
| Single Row Cylindrical Roller | Bearing In Accordance with ISA Dimension Series 10 | 70mm - Bore Size | Tapered Bore, Taper 1:12 | Glass Fibre Reinforced PEEK Cage, Outer Ring Centred | Bearing Grade Silicon Nitrade Si3N4 | Precision Rating |
Product Information
SKU: Availability:
In Stock ✅
Technical Data
Inside Diameter (mm)
70mm
Outside Diameter (mm)
110mm
Width (mm)
20mm
Cage Type
Plastic
Seals Or Shields
Open Type
Clearance
Standard
Dynamic Load Rating (kN)
55
Static Load Rating (kN)
72
Fatigue Load Rating (kN)
8.3
Grease Limiting Speed (r/min)
15000
Oil Limiting Speed (r/min)
20000
DescriptionThis N1014KTNHA/HC5SP bearing is a single row super precision cylindrical roller bearing with a double ribbed inner ring, a glass fibre reinforced PEEK cage, a 1:12 tapered bore and a P5 accuracy class.. The bearing's dimensions are 70x110x20.
Product InformationBRANDS: SKU: n1014ktnha/hc5sp-skf Availability:In Stock ✅ 0.55 kg Technical DataInside Diameter (mm)70mm Outside Diameter (mm)110mm Width (mm)20mm Cage TypePlastic Seals Or ShieldsOpen Type ClearanceStandard Dynamic Load Rating (kN)55 Static Load Rating (kN)72 Fatigue Load Rating (kN)8.3 Grease Limiting Speed (r/min)15000 Oil Limiting Speed (r/min)20000 | ||||||||||||||
Product InformationBRANDS: SKU: n1014ktnha/hc5sp-skf Availability:In Stock ✅ 0.55 kg Technical DataInside Diameter (mm)70mm Outside Diameter (mm)110mm Width (mm)20mm Cage TypePlastic Seals Or ShieldsOpen Type ClearanceStandard Dynamic Load Rating (kN)55 Static Load Rating (kN)72 Fatigue Load Rating (kN)8.3 Grease Limiting Speed (r/min)15000 Oil Limiting Speed (r/min)20000 | ||||||||||||||
Bulk PricingFor bulk discount on this product, contact our dedicated sales team today by filling out the form below: | ||||||||||||||
