IKO
SKU: naf173516-iko
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
The NAF173516 is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. Both the Inner and Outer Ring are easily separable from the Needle Roller Cage. The Needle Roller Cage means that these Bearings have excellent rotational performance and a simple structure with high accuracy. These Bearings are most suitable for mass-production, high running accuracy applications like Machine Tools, Printing Equipment, and Textile Machinery. The bearing dimensions are 17X35X16MM.
The INA equivalent is NAO17x35x16-XL.
| NAF | 17 | 35 | 16 | |
|---|---|---|---|---|
| Single Row Caged Needle Roller Bearing | 17mm Bore | 35mm OD | 16mm Width | Including Inner Ring |
17
35
16
22
17.6
20.9
NAO17x35x16-XL
25000
120°C/248°F
-20°C/-4°F
DescriptionThe NAF173516 is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. Both the Inner and Outer Ring are easily separable from the Needle Roller Cage. The Needle Roller Cage means that these Bearings have excellent rotational performance and a simple structure with high accuracy. These Bearings are most suitable for mass-production, high running accuracy applications like Machine Tools, Printing Equipment, and Textile Machinery. The bearing dimensions are 17X35X16MM. The INA equivalent is NAO17x35x16-XL.
Product InformationBRAND: SKU:naf173516-iko AVAILABILITY:In Stock ✅ WEIGHT:0.09 kg Technical DataInside Diameter (mm):17 Outside Diameter (mm):35 Width (mm):16 Nominal Roller Set Bore Diameter (mm):22 Dynamic Load Rating (kN):17.6 Static Load Rating (kN):20.9 INA Equivalent:NAO17x35x16-XL Allowable Rotational Speed (r/min):25000 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||||||
Bulk PricingFor bulk discount on this product, contact our dedicated sales team today by filling out the form below: | ||||||||||
