IKO
RNA4920UU IKO Machined Needle Roller Bearing - 115X140X40MM
SKU
: rna4920uu-iko
Availability
: In Stock ✅
Bulk Pricing :
Description
The RNA4920UU is a Standard Duty, Single Row Machined Needle Roller Bearing with an oil groove, an oil hole in the Outer Ring, and 2 Rubber Seals. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 115X140X40mm.
RNA | 49 | 20 | UU |
---|---|---|---|
Single Row Caged Needle Roller Bearing | Dimension Series 49 | 115mm - Bore Size | 2 Rubber Seals |
Product Information

Availability:
In Stock ✅
Technical Data
Inside Diameter (mm)
115
Outside Diameter (mm)
140
Width (mm)
40
Nominal Roller Set Bore Diameter (mm)
115
Dynamic Load Rating (kN)
134
Static Load Rating (kN)
297
Allowable Rotational Speed (r/min)
1700
Max. Operating Temperature
120°C/248°F
Min. Operating Temperature
-20°C/-4°F
Seals Or Shields
Two Rubber Seals
DescriptionThe RNA4920UU is a Standard Duty, Single Row Machined Needle Roller Bearing with an oil groove, an oil hole in the Outer Ring, and 2 Rubber Seals. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 115X140X40mm.
Product InformationBRANDS: ![]() rna4920uu-iko Availability:In Stock ✅ 1.2 kg Technical DataInside Diameter (mm)115 Outside Diameter (mm)140 Width (mm)40 Nominal Roller Set Bore Diameter (mm)115 Dynamic Load Rating (kN)134 Static Load Rating (kN)297 Allowable Rotational Speed (r/min)1700 Max. Operating Temperature120°C/248°F Min. Operating Temperature-20°C/-4°F Seals Or ShieldsTwo Rubber Seals | ||||||||
Product InformationBRANDS: ![]() rna4920uu-iko Availability:In Stock ✅ 1.2 kg Technical DataInside Diameter (mm)115 Outside Diameter (mm)140 Width (mm)40 Nominal Roller Set Bore Diameter (mm)115 Dynamic Load Rating (kN)134 Static Load Rating (kN)297 Allowable Rotational Speed (r/min)1700 Max. Operating Temperature120°C/248°F Min. Operating Temperature-20°C/-4°F Seals Or ShieldsTwo Rubber Seals | ||||||||
